The BZM55B9V1 is a 9.1V Zener diode manufactured by Vishay. This diode is designed to provide stable voltage regulation and overvoltage protection in various electronic circuits. It is available in a SOD-80C package, suitable for surface mounting on printed circuit boards.

Applications:

• Voltage regulation in consumer electronics.
• Overvoltage protection in portable devices.
• Clipping and clamping circuits in signal processing.
• Voltage reference in power supplies.

Features

• Zener Voltage of 9.1V.
• SOD-80C package for surface mount assembly.
• Low reverse leakage current.
• High power dissipation capability.

Benefits

• Provides stable voltage regulation, ensuring consistent circuit performance.
• Offers reliable overvoltage protection, preventing damage to sensitive components.
• Compact size allows for use in space-constrained applications.
• High surge current capability protects against transient voltage spikes.

Additional Details: The BZM55B9V1 has a power dissipation of 500 mW. The operating temperature range is typically from -55°C to +150°C. The forward voltage is typically 0.9V at a forward current of 10mA. It is RoHS compliant. For detailed electrical characteristics, performance graphs, and application notes, consult the official Vishay datasheet for the BZM55B9V1 Zener diode.
