Overview of SN74LV1T34DBVR

The SN74LV1T34DBVR is a cutting-edge, single-bit, non-inverting buffer/driver from Texas Instruments, designed to operate over a wide voltage range of 1.8 V to 5.5 V. This device is optimized for low-voltage applications, including portable electronics, where power efficiency is a critical parameter. The SN74LV1T34DBVR is part of the SN74LV1T34 series, which is known for its high drive strength and low power consumption.

Key Features

• Wide Operating Voltage Range: This device can function across a broad voltage range from 1.8 V to 5.5 V, making it versatile for use in various circuits and systems.
• Low Power Consumption: It is designed for low power operation, which conserves energy and extends battery life in portable applications.
• High Output Drive: Despite its low power usage, the SN74LV1T34DBVR is capable of driving high-current loads, offering robust performance for a single-bit buffer/driver.
• Compatibility: The input and output voltage levels are compatible with LVCMOS technology, ensuring easy integration with a wide range of digital circuits.
• Compact Package: Housed in a small SOT-23-5 package, the SN74LV1T34DBVR is ideal for space-constrained applications.

Applications

The versatile nature of the SN74LV1T34DBVR makes it suitable for a broad array of applications, including:

• Portable and battery-powered devices
• Logic level translation
• Signal buffering
• Bus driving
• Clock distribution

Product Specifications

The SN74LV1T34DBVR boasts a propagation delay time of typically 3.4 ns at 3.3 V, enabling fast signal processing. The device also features a low input capacitance and a ±24-mA output drive at 3.3 V. It is available in a 5-pin SOT-23 package, which is RoHS compliant and designed for surface-mount technology (SMT).

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the SN74LV1T34DBVR is no exception. It is manufactured to the highest standards, ensuring reliable performance in even the most demanding applications. The device is also supported by comprehensive technical documentation and Texas Instruments' customer support.
