The 710975-LTV-827S-TA1-B is an active optoisolator with a transistor output, manufactured by Lite-On Inc.

• Series: LTV-8x7
• Package Type: Tape and Reel
• Standard Package: 1,000 pieces
• Input: DC
• Maximum Forward Current (If): 50mA
• Forward Voltage (Vf): 1.2V (typical)
• Rise Time: 4μs
• Fall Time: 3μs
• Output Current per Channel: 50mA
• Channels: 2
• Isolation Voltage: 5000Vrms
• Current Transfer Ratio (Minimum): 50% @ 5mA
• Maximum Output Voltage: 35V
• Maximum Vce Saturation: 200mV
• Current Transfer Ratio (Maximum): 600% @ 5mA
• Package Type: Surface Mountable, 8-SMD, gull-wing
• Operating Temperature: -30°C to 100°C
• ECCN: EAR99
• Counterfeit Risk: 48%
• HTSUS Code: 8541.49.8000
